Type SHD-GC Mining Shovel Power Trailing Cable 4/0 AWG 3C 5kV

**Type SHD-GC Mining Power Trailing Rubber Cable 4/0 AWG 3C 5kV**

**Key Features:**

- **Conductor Core:** Crafted with 6 AWG through 500 kcmil coated annealed copper conductors, bunched wires, and rope-lay-stranded construction per ASTM B172, offering flexibility and durability for seamless handling and installation.

- **Insulation:** Ethylene Propylene Rubber (EPR) insulation provides exceptional resistance to heat, moisture, steam, oil, chemicals, and radiation, ensuring unwavering performance in harsh mining conditions.

- **Insulation Shield:** Flexible coated copper/textile braid shield, applied over non-conducting overlapped tape, provides superior protection against external interference, bolstering signal integrity and reliability.

- **Ground Check Conductor:** Featuring annealed copper, rope-lay-stranded per ASTM B172, insulated with high-strength yellow polypropylene for fail-safe monitoring and heightened operational safety.

- **Grounding Conductors:** Utilizing coated copper, rope-lay-stranded per ASTM B172, with two conductors in contact with the flexible copper braid shield, offering additional grounding for enhanced safety.

- **Jacket:** Reinforced, two-layer, extra-heavy-duty, lead-cured Chlorinated Polyethylene (CPE) jacket provides maximum safeguarding against mechanical damage, including cutting, impact, abrasion, flame, and sunlight exposure, ensuring prolonged performance.

**Applications:**

- Trailing cables on AC mining equipment

- Compatibility with Bretby-type cable handling devices on longwall shearers

- Ideal for low- and medium-voltage AC circuits requiring enhanced shielding

- Suitable for applications necessitating ground-check conductors for fail-safe monitoring

**Specifications:**

- Size: 4/0 AWG

- Number of Conductors: 3

- Conductor Strand: 532

- Ground Conductor AWG Size: 1

- Ground Check AWG Size: 8

- Nominal Insulation Thickness: 0.110 inches / 2.8 mm

- Outside Diameter: 2.50 inches / 63.5 mm

- Current AMPS: 321

- Net Weight: 5.265 lbs per ft

The SHD-GC Mining Power Trailing Rubber Cable 4/0 AWG 3C 5kV ensures robust power distribution and safety in mining applications, guaranteeing reliability and performance in challenging environments.

Note: This is just part of the standard parameters of our products. Please contact our Engineer if you need more. And the information contained within this webpage is for guidance only and is subject to change without notice or liability. All dimensions and specifications are nominal and are subject to normal manufacturing tolerances. All pictures shown are for illustration purposes only. The actual product may vary. All the information is provided in good faith and is believed to be correct at the time of publication.
