Type SHD-GC Dragline Mining Power Trailing Cable 300 MCM 3C 5kV

**Type SHD-GC Dragline Mining Power Trailing Cable 300 MCM 3C 5kV**

**Overview:**

The SHD-GC Dragline Mining Power Trailing Cable is specifically designed to meet the rigorous demands of dragline mining operations, providing reliable power distribution and ensuring safety in challenging environments.

With advanced features and robust construction, this cable offers superior performance and durability for mining applications.

**Key Features:**

- **Conductor:** Constructed with 6 AWG thru 500 kcmil coated annealed copper conductors, bunched wires, and rope-lay-stranded per ASTM B172, ensuring flexibility and durability for seamless installation and handling in harsh mining conditions.

- **Insulation:** Ethylene Propylene Rubber (EPR) insulation provides excellent resistance to heat, moisture, steam, oil, chemicals, and radiation, ensuring reliable performance in extreme environments.

- **Insulation Shield:** Equipped with a flexible coated copper/textile braid shield, applied over non-conducting overlapped tape, providing superior protection against external interference and maintaining signal integrity.

- **Ground Check Conductor:** Featuring annealed copper, rope-lay-stranded per ASTM B172, insulated with high-strength yellow polypropylene, for fail-safe monitoring and enhanced operational safety.

- **Grounding Conductors:** Utilizing coated copper, rope-lay-stranded per ASTM B172, with two conductors in contact with the flexible copper braid shield, providing additional grounding for increased safety.

- **Jacket:** Reinforced, two-layer, extra-heavy-duty, lead-cured Chlorinated Polyethylene (CPE) jacket offers maximum protection against mechanical damage, including cutting, impact, abrasion, flame, and sunlight exposure, ensuring long-lasting performance in harsh mining environments.

**Applications:**

- Designed for use as trailing cables on AC mining equipment
- Ideal for dragline operations in mining applications
- Compatible with Bretby-type cable handling devices on longwall shearers
- Suitable for low- and medium-voltage AC circuits requiring enhanced shielding

**Specifications:**

The SHD-GC Dragline Mining Power Trailing Cable 300 MCM 3C 5kV ensures reliable power distribution and safety in dragline mining operations, offering durability and performance in the most demanding conditions.

Note: This is just part of the standard parameters of our products. Please contact our Engineer if you need more. And the information contained within this webpage is for guidance only and is subject to change without notice or liability. All dimensions and specifications are nominal and are subject to normal manufacturing tolerances. All pictures shown are for illustration purposes only. The actual product may vary. All the information is provided in good faith and is believed to be correct at the time of publication.
