ICEA S-75-381/NEMA WC-58 Type SHD-GC 2kV Mining Grade Round Portable Power Cable
Your Go-To Solution for Heavy-Duty Mining Applications
When it comes to powering heavy-duty mining and industrial equipment, Type SHD-GC 2kV Mining Grade Portable Power Cable offers unparalleled performance, durability, and flexibility.
Designed specifically for applications like long wall miners, loaders, drills, shovels, conveyors, pumps, and mobile equipment that require grounding conductors and a ground check conductor with metallic shielding, this cable is a reliable partner in demanding environments.
The ICEA S-75-381/NEMA WC-58 compliance ensures that this power cable meets the highest standards, making it an industry favourite for safety and resilience.
Why Choose Type SHD-GC 2kV Portable Power Cable?
The Type SHD-GC 2kV Portable Power Cable for Mining Applications is engineered with advanced materials that provide exceptional flexibility, heat resistance, and rugged durability.
These qualities make it ideal for use in harsh environments such as underground mining, where extreme temperatures, moisture, and abrasive conditions can affect cable performance.
Key Features at a Glance:
2kV Rated Power Cable for high-performance power delivery
Heavy-Duty Construction designed to withstand extreme mining conditions
Flexible Cable for easy installation and movement in tight spaces
Grounding Conductors and Ground Check Conductor for enhanced safety
Metallic Shielding for EMI/RFI protection and improved signal integrity
Black Poly-chloroprene (CR) Outer Jacket for high torsion resistance and longevity
Product Construction and Specifications
Cable Components and Materials
Each element of the Type SHD-GC cable is carefully selected to meet specific requirements:
| Component | Description |
| Conductors | Soft-drawn flexible stranded tinned copper wires |
| Separator | Polyester tape |
| Insulation | Ethylene-propylene rubber (EPR) |
| Insulation Shield | Non-conductive bedding tape + composite tinned copper/polyamide braid covering at least 60% |
| Circuit ID | Black, white, and red polyamide in shielding braid |
| Grounding | Soft-drawn flexible stranded tinned copper wires |
| Ground Check | Yellow PP insulated soft-drawn flexible stranded tinned copper |
| Jacket | Extra heavy-duty, reinforced poly-chloroprene (CR) |
| Colour | Black (other colours and TPU jacket available on request) |
Electrical and Mechanical Specifications
| Property | Details |
| Voltage Rating | 2kV |
| Operating Temperature | -40ºC to +90ºC |
| Minimum Bending Radius | 8x the overall diameter |
| Flame, Oil, and Heat Resistance | Yes |
| Abrasion Resistance | High |
| Weather and Sun Resistance | Yes |
Performance and Reliability
This Heavy-Duty Cable is crafted with durability in mind, capable of enduring intense operational demands.
The poly-chloroprene jacket offers enhanced torsion resistance, impact protection, and resistance to environmental conditions like sunlight, ozone, and oil. This feature ensures minimal wear and tear, even in continuous operation.
Applications of Type SHD-GC 2kV Power Cable:
The cable is ideal for a variety of mining and industrial applications, including:
Long wall miners
Loaders
Drills
Shovels
Conveyors
Pumps
Mobile equipment in underground and open-pit mining
With its flexible power cable design, this cable ensures uninterrupted power delivery in confined, rugged environments, providing maximum operational uptime for mission-critical equipment.
Selection Data
When selecting the appropriate cable size, consider factors such as conductor size, insulation thickness, and overall dimensions. Below is a sample of available specifications for the Type SHD-GC 2kV:
| Part Number | Cond. Size | Cond. Strand | Jacket Thickness (mm) | Outside Diameter (mm) | Approx. Weight (kg/km) | Max. Tensile Force (N) |
| SHDGC2KV8-3* | 8 AWG | 133 | 3.94 | 27.2 | 1137 | 380 |
| SHDGC2KV6-3 | 6 AWG | 133 | 3.94 | 31.6 | 1545 | 600 |
| SHDGC2KV4-3 | 4 AWG | 259 | 3.94 | 34.3 | 1980 | 950 |
| SHDGC2KV2-3 | 2 AWG | 259 | 4.32 | 38.9 | 2702 | 1500 |
| SHDGC2KV1-3 | 1 AWG | 259 | 4.83 | 43.0 | 3313 | 1900 |
Enhanced Durability with Advanced Shielding and Jacket Options
For applications where electromagnetic interference is a concern, the metallic shielding provides additional protection.
The jacket is also customizable, with options for TPU jackets and various colours available upon request to suit specific operational needs and branding preferences.
Electrical Resistance and Power Data
| Conductor Size (AWG/MCM) | Conductor Resistance @ 25°C (Ω/1000ft) | Grounding Conductor Resistance (Ω/1000ft) | Ground Check Conductor Resistance (Ω/1000ft) | Short-Circuit Current (kA) | Ampacity (40°C Ambient Temp) |
| 6 AWG | 0.436 | 1.08 | 1.08 | 1.90 | 93 |
| 4 AWG | 0.274 | 0.679 | 1.08 | 3.03 | 122 |
| 2 AWG | 0.172 | 0.436 | 0.679 | 4.80 | 159 |
| 1 AWG | 0.137 | 0.346 | 0.679 | 6.06 | 184 |
This table allows customers to make precise calculations based on cable length, temperature, and expected load, aiding in selecting the most suitable cable for their specific applications.
Ampacity and Short-Circuit Current Ratings
The Type SHD-GC 2kV cable can carry a high amount of current continuously at an operating temperature of up to 90ºC and withstand short-circuit currents up to 250ºC.
This capacity makes it highly reliable for sustained, demanding applications.
Special Factory Options
Customizable Jacket: TPU jackets and alternative colour options are available for tailored applications.
Additional Shielding: Enhanced metallic shielding options for applications requiring high levels of signal integrity.
Why Type SHD-GC 2kV Is a Superior Choice for Mining and Industrial Needs
In mining and industrial settings, safety, reliability, and flexibility are paramount. This mining-grade cable offers unmatched resilience against moisture, abrasion, and mechanical stress, with advanced shielding and grounding to protect personnel and equipment from electrical hazards.
Invest in the Type SHD-GC 2kV Portable Power Cable to achieve peace of mind and operational efficiency in some of the world’s most challenging environments. This cable delivers power and protection where it’s needed most, ensuring that mining operations stay productive and safe.
Whether you're managing long wall miners, underground loaders, or mobile conveyors, the Type SHD-GC 2kV Mining Grade Cable is built to handle it all with ease.
For more information on configurations and options, contact our technical team and elevate your mining operations with the best in mining-grade cable technology.
Note: This is just part of the standard parameters of our products. Please contact our Engineer if you need more. And the information contained within this webpage is for guidance only and is subject to change without notice or liability. All dimensions and specifications are nominal and are subject to normal manufacturing tolerances. All pictures shown are for illustration purposes only. The actual product may vary. All the information is provided in good faith and is believed to be correct at the time of publication.
